Nickel alloys are metals created by combining nickel with another material as the primary element. It combines two materials to produce more desirable properties like increased strength and corrosion resistance. It's used in a wide range of equipment across multiple industries due to its distinct properties. Apex Metal India is a leading supplier and stockiest of nickel in all grades.
MONEL R 405 is a Nickel-Copper alloy, resistant to sea water and steam at high temperatures as well as to salt and caustic solutions.
MONEL R405 is a nickel-copper alloy with excellent corrosion resistance in a wide variety of media. MONEL R405 is characterized by good general corrosion resistance and moderate to high strength. MONEL R405 has been used in a variety of applications. It has excellent resistance to rapidly flowing brackish water or seawater.
It is particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated. MONEL R405 is slightly magnetic at room temperature. MONEL R405 is widely used in the chemical, oil and marine industries.
| - | Ni | Cu | Fe | S | Mn | C | Si |
|---|---|---|---|---|---|---|---|
| Max | - | 34.0 | 2.5 | 0.060 | 2.0 | 0.3 | 0.5 |
| Min | 63.0 | 28.0 | 0.025 |
| Ultimate Tensile | Yield Strength (0.2% OS) | Elong. in 2 in. or 50mm or 4D, min., % | R/A | Hardness | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Cold Worked/SR | |||||||||||
| Min | 85 KSi | 50 KSi | 15 | ||||||||
| Max | |||||||||||
| Min | 585 MPa | 345 KPa | |||||||||
| Max | |||||||||||
| Hot Worked/SR | |||||||||||
| Min | 75 KSi | 35 KSi | 30 | ||||||||
| Max | |||||||||||
| Min | 517 MPa | 241 MPa | |||||||||
| Max | |||||||||||
