Nickel alloys are metals created by combining nickel with another material as the primary element. It combines two materials to produce more desirable properties like increased strength and corrosion resistance. It's used in a wide range of equipment across multiple industries due to its distinct properties. Apex Metal India is a leading supplier and stockiest of nickel in all grades.
HASTELLOY C 276 is a Nickel-chromium-molybdenum wrought alloy that is considered the most versatile corrosion resistant alloy available. This alloy is resistant to the formation of grain boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process applications in an as welded condition.
Alloy C-276 also has excellent resistance to pitting, stress-corrosion cracking and oxidizing atmospheres up to 1900°F. Alloy C-276 has exceptional resistance to a wide variety of chemical environments.
The chemical composition nickel Hastelloy C 276 is outlined in the following table.
| - | Ni | Cr | Mn | Mo | C | Si | Fe |
|---|---|---|---|---|---|---|---|
| Max % | Bal | 16.5 | 1.0 | 17.0 | 0.010 | 0.08 | 7.0 |
| Min % | 14.5 | 15.0 | 4.0 |
| - | Ultimate Tensile | Yield Strength (0.2% OS) | Elong. in 2 in. (50.8mm) or 4D min., % | R/A | Hardness |
|---|---|---|---|---|---|
| Min | 100 KSi | 41 KSi | 40 | ||
| Max | |||||
| Min (Metric) | 690 MPa | 283 MPa | |||
| Max |
